| Capacity in Tons |
10 Ton |
20 Ton |
30 Ton |
50 Ton |
75 Ton |
100 Ton |
150 Ton |
200 Ton |
250 Ton |
300 Ton |
| Bed Size |
12”x14”
305x355 |
14”x16”
355x405 |
16”x18”
405x457 |
19”x20”
482x508 |
22”x23”
560x585 |
25”x27”
635x685 |
27”x29”
685x735 |
32”x32”
812x812 |
36”x36”
915x915 |
40”x40”
1015x1015 |
| Bed to Ram |
10”/254 |
11”/280 |
12”/305
|
14”/335 |
17”/430 |
19”/480 |
20”/508 |
22”/560 |
24”/610 |
| Bed Bore |
4”/100 |
4½”/115 |
5”/127 |
6”/150 |
7”/175 |
8”/200 |
9”/225 |
10”/250 |
11”/275 |
12”/300 |
| Gear Dia |
18”/457 |
22”/560 |
24”/610 |
26”/660 |
30”/762 |
34”865 |
38”/965 |
42”/1065 |
48”/1220 |
54”/1370 |
| Fly Wheel Dia |
21”/533 |
25”/635 |
28”/710 |
32”/812 |
36”/915 |
39”/990 |
44”/1117 |
48”/1220 |
52”/1320 |
56”/1420 |
| Crank Shaft Dia |
3”/75 |
3½”/90 |
4”/100 |
4¾”/118 |
5½”/140 |
6½”/165 |
7½”/190 |
8¼”/210 |
9”/230 |
10”/255 |
| Back Shaft Dia |
2¼”/55 |
2½”/65 |
2¾”/70 |
3 1/8”/80 |
3½”/90 |
4”/100 |
4¾”/118 |
5”/125 |
5½”/140 |
6”/150 |
| Stroke |
2¼”/55 |
2½”/63 |
3”/75 |
3½”/90 |
4”/100 |
4½”/115 |
5”/125 |
5½”/140 |
6”/150 |
6½”/165 |
| Hole in Ram Die Clamping |
9/8”/28mm |
1¼”/32mm |
1 3/8”/35mm |
1½/38mm |
1¾”/45mm |
2”/50mm |
2¼”/55mm |
2 3/8”/60mm |
2½”/65mm |
2¾”/70mm |
| No. of Stokes |
75 |
65 |
60 |
60” |
55 |
50 |
45 |
40 |
35 |
30 |
| Pulley size |
5”
|
6” |
6” |
7” |
7” |
7” |
7” |
7” |
7” |
7" |
| Total Height |
64 |
70 |
76 |
81 |
87 |
93 |
102" |
112” |
120” |
135 |
| Motor Required |
1 H.P. |
2 H.P. |
3 H.P. |
5 H.P. |
5 H.P. |
7½ H.P. |
10 H.P. |
15 H.P. |
20 H.P. |
30.H.P |
| Floor to Top of Bed |
28” |
29” |
30” |
30” |
30” |
30” |
30” |
30” |
30” |
30" |
|
|
